Introduction to PassThru (J2534) Programming
The EPA has mandated that all 2004 model cars must support the SAE J2534 standard. What is this new standard and what does it mean for you?
First, some history:
The EPA has long been interested in automobiles. In 1994, the EPA mandated that all light-duty vehicles have a standard connector for On-Board Diagnostics (OBD). The SAE (Society of Automotive Engineers) created the OBD standard, also known as 'J1962'. This standard specifies the size, position and design of the OBD connector. Anyone can plug a device (called a scan tool) into the connector to monitor the car's emissions and review any recent emission-related faults.
A computer in the car called the Engine Control Unit (ECU) controls the fuel injection, spark plugs and (indirectly) the car's emissions. The software running on the ECU is called 'firmware' because it's more difficult to change than normal software. One ECU can be used in many different car models with only slight changes to the ECU firmware. In fact, one car model can comply with emission laws in different countries just by modifying the firmware. Upgraded firmware can fix bugs and tighten emissions output well after a car leaves the factory.
The EPA wants more:
The EPA quickly realized that a car's emissions are only as good as the firmware on the ECU. Until now, only auto dealers were able to upgrade the ECU firmware with tools that sometimes cost as much as the car itself. Starting with model year 2004, the EPA wants anyone (including auto repair shops and car enthusiasts) to be able to upgrade their car 'for a reasonable cost.' To accomplish this, they asked SAE to create the J2534 API.
What is an API?
An API (Application Programming Interface) is a 'rendezvous point' between two pieces of software. For example, any Windows application (such as MS Word and Photoshop) can print to any printer. How is this possible? The application and the printer driver communicate via an API. Even though each printer has different hardware, all printer drivers 'look the same' to Windows applications. You are free pick any printer based on your preferences (color, size, durability, cost, speed) without worrying about software incompatibilities. In a similar vein, the J2534 API makes all 'car communications' hardware look the same.
The Software
The EPA is forcing car manufacturers to release software that updates the firmware on their cars. The application must run on Windows and use the J2534 API to talk to the car. Anyone can buy this software, even individual car enthusiasts. The software must be sold 'for a reasonable price', which will probably be a few hundred dollars.
The Hardware
A J2534 device plugs into a cars' OBD connector on one side, and a computer on the other side. These devices are not made by car manufacturers, but by any company that sees an opportunity. Under the hood, the device must speak a myriad of different vehicle protocols (ISO9141, J1850VPW/PWM, CAN, etc.) used by the different manufacturers. Each protocol has different voltage and timing requirements, so this is no trivial task. Fortunately, each device comes with a software driver that implements the J2534 API. Since the driver invisibly handles communication to the device, application software writers don't have to worry about the connection details or low-level car protocols.
What's it good for?
The combination of 'reasonable cost' ECU upgrade software and competition among J2534 device manufacturers will create new markets. We predict that car repair shops and some car enthusiasts will find it profitable to charge for ECU upgrades. Imagine pulling into Midas or Jiffy Lube and learning, 'Your car manufacturer recommends new ECU firmware. It will cost a few dollars, but it will help your engine run cleaner.' By purchasing the upgrade, consumers will be helping to cleanup the environment.
Here's what this means for you
For ordinary car users, this means that your car can be fully serviced in any garage. No longer will you have to pay the dealer's monopoly price for firmware upgrades. The latest firmware might offer better gas mileage, or just the pleasant feeling of lower emissions. It might also make ECUs cheaper, since retailers will be able to stock one ECU and reprogram it for many related car models.
For car enthusiasts, performance-enhancing firmware will get easier to install. Even better, 'downgrading' back to the original firmware will be easier too. A lot of the 'enhanced' firmware is not 'street legal' because it has not been EPA approved. J2534 will allow weekend warriors to upgrade their car when they race on a track, then return to regulation firmware for the Monday commute.
For car manufacturers, it means the extra hassle of writing and selling software. On the other hand, it will be easier to fix emissions problems in the future. If the EPA finds an emissions-related problem, upgrades can be made available to the consumer at their nearest car repair shop instead of recalling millions of cars back to the dealers.
Conclusion
J2534 is a definite a win-win situation for consumers, manufacturers, environmentalists and car enthusiasts. The EPA is using open standards and the free market to help keep cars in tip-top shape.
The EPA legislation can be found by clicking HERE.

INPA BMW cable is the strong diagnostic cable for BMW.Many client got problem with tool set error when using .Here vxdas.com share INPA BMW tool set error messages trouble shooting.Hope it can help every INPA BMW owner.

INPA BMW Tool Set Error Messages Trouble Shooting

1.EDIABAS error 100: SYS-0010: INITIALIZATION ERROR

Reason: This message comes when an SGBD has an automatic concept switch between
multiple diagnostics logs and is not connected to the controller.
Solution: Connect the controller

2.EDIABAS Error 126 (only up to Ediabas V6.4.x)

Reason: This error message appears if you start the Tool Set while an INPA BMW script is
running. This is also true the other way round. The reason for this is that only one
programme can access EDIABAS at a time.
Solution: Therefore, before you start the ToolSet, you must exit INPA!!!

3.IFH-0006: Command not accepted and IFH-0018: Initialization Error and
IFH-0038: Interface Command not implemented

Errors IFH-0006 and IFH-0018 occur if any SGBD is loaded in the Tool Set. Error IFH-0038
is generated when loading the utility file into the Tool Set.
Reason 1: The error was caused by another programme that accessed the COM1
interface. This programme could be “HotSync” for Palm or “ActiveSync”
for lpack.
Solution 1: Check the programmes that are started automatically when Windows is
started (see Chapter 4.1).
Reason 2: The COM1 interface is taken by a serial printer.
Solution 2: Uninstall the printer.
Reason 3: The infrared interface is active.
Solution 3: Deactivate the infrared interface.
Reason 4: There is no COM1 interface (COM3 instead, for example)
Solution 4a): Install the COM1 interface.
Solution 4b): Create a file with the name OBD.ini and make the following entry to set
the existing serial interface (COM3, for example)

[OBD]
Port = Com3
The file OBD.ini must be saved in the directory C:WINDOWS for
Windows XP or in directory C:WINNT for Windows NT up to the Ediabas
Package 1.3 and as of Ediabas Package 1.4 in directory
C:EDIABASBIN. The current version of the Ediabas Package can be
seen in the files C:EDIABASversion.txt or C:EDIABASpackage.pdf.
Reason 5: Only for IBM notebooks: The COM1 interface is reserved for the docking
station; the COM3 interface is installed instead.
Solution 5a): see solution 4b:
Solution 5b): Set the COM3 port to COM1: In the device manager (Windows XP:
Select “Start” “Control Panel” “System” “Hardware” and then
select COM3 from the ports under the menu item “Device Manager”.
Then use the right mouse button “Properties” “Port Settings”
“Advanced” to reach the “Advanced Settings for COM3”. Set COM1 in the
COM Port Number. The message that COM1 is already taken can be
ignored in this case.
Reason 6: The old OMITEC driver wasn’t uninstalled correctly.
Solution 6: Please uninstall the old OMITEC driver with the instructions
InstructionforOMITECInstallation.pdf via the GIS server

4 IFH-0006: Command not accepted

This error occurs if a SGBD is loaded in the Tool Set when the OBD connector is being used.
Reason 1: ODB has actually been set as the interface in Ediabas.ini, but the Tool Set uses
the multi-instance with another interface, e.g. K-Line. The setting for the multi0002instance and the interfaces used here is made in the file Tool32.ini in the
directory C:Windows (for Windows XP) or alternatively C:Winnt (for Windows
NT). Then, the entries in Tool32.ini, or alternatively the interface apply and not
the ones in Ediabas.ini. The use of multi-instance in the Tool Set is identified in
the title bar, for example with “Tool32:1”, for single multi-instance.
Solution 2: Enter the interface that is being used in Tool32.ini or disable multi-instance with
the entry “No”.
Reason 2: A SGBD is loaded in the Tool Set when the diagnosis protocol UDS is being
used. For UDS-SGBDs You have to use the interface OMITEC but in the
EDIABAS.ini the setting fort he interface ist „STD:OBD“.
Solution 2: Change the setting for thr interface to „interface = STD:OMITEC“ in the
EDIABAS.ini file. The OMITEC connector has to be stressed by the voltage (blue
blinking). If the connector can’t be stressed by the voltage and You want to load
the SGBD yet, You will use the simulation mode. You can activate the simulation
mode e.g. with the menue „configuration -> EDIABAS“. Notice, if you want to use
the simulation mode, a simulation file for the interface will have to exist in the
simulation path.

5 IFH-0009: ECU isn’t connected or doesn’t respond

Drivers Technical Support Epson

Reason 1: In the Ediabas.ini file, the interface is set to STD:ADS. However, you have
connected an OBD connector.
Solution 1: Modify the interface setting.
Reason 2: The ignition is switched off.
Solution 2: Switch the ignition on.
Reason 3: The device manager has been used to disable the FIFO buffer for COM1.
Solution 3: In the device manager (Windows XP: Enter “Start” “Control Panel”
“System” “Hardware” “Device Manager” Ports (COM & LPT)), and select
COM1 from the ports and under the “Port Settings” tab, select “Advanced”. There
must be a check-mark by “Use FIFO buffers” and the highest possible setting
must be selected for the receive buffer.

6 SYS-0002: ECU OBJECT FILE NOT FOUND

Schuhfried driver download for windows 10 32-bit. Reason 1: If the external table T_GRTB.prg doesn’t exist in the directory C:EDIABASECU
the error message will be displayed when You execute the job
IDENT_FUNKTIONAL of a functional SGBD.
Solution 1: You have to download the external table using the ECCO Web Export and copy it
in the directory C:EDIABASECU.
Reason 2: The SGBD, which You want to start doesn’t exist in the directory
C:EDIABASECU or is an old one.
Solution 2: You have to download the SGBD using the ECCO Web Client and copy it in the
directory C:EDIABASECU

7 SYS-0005: Controller description file not found. The programme will be
aborted!

Reason 1: The SGBD is not located in the path C:EdiabasEcu.
Solution 1: Copy the SGBD into the Ecu directory.
Reason 2: This error occurs if the EcuPath in Ediabas.ini (C:EdiabasBin) isn’t set to
C:EDIABASECU.
Solution 2: Set the correct path

8 ToolSet Error: Runtime error ’372’

Drivers Teclado Apple Windows 10

The following error message appears.

Roline driver download for windows. Reason: The old version msflxgrd.ocx exists under c:winntsystem32.
Solution: msflxgrd.ocx under c:Ediabasbin must be registered. To do this, select “Start”
“Run…” and execute regsvr32 :ediabasbinmsflxgrd.ocx in the window and
confirm with “OK“.
The following must be entered for Windows XP: “regsvr32 c:ediabasbin
msflxgrd.ocx

9 INPA BMW Tool Set Error: Run-time error ’5’ – Invalid Procedure Call

Reason: The Tool Set was started twice in a very short period of time.
Solution: Close all Tool Set processes that are running and start the Tool Set again with
only one double-click

10 INPA BMW Tool Set Problem: If an SGBD is opened, then only the hourglass
appears and the SGBD is not loaded.

Drivers Technology Definition

Reason: An old version Richtx32.ocx exists under c:winntsystem32.
Solution: Richtx32.ocx under c:Ediabasbin must be registered. To do this, select “Start”
“Run…” and execute “regsvr32 :ediabasbinrichtx32.ocx“ in the window and
confirm with „OK“.
The following must be entered for Windows XP: „regsvr32 c:ediabasbin
richtx32.ocx

11 INPA BMW EDIABAS error 20: IFH-0010: Data transmission to control unit
disturbed

Reason 1: When using the EDIC card, the error message is issued when executing the
IDENT job.
Solution 1: Changes must be made in the file “XEDICC.ini” in the “…EdiabasBin” directory.
There, the parameters set for high-speed must be commented out and the
parameters for low-speed must be enabled:

; highspeed:
;Interface=1;
;Presc=0x01;
;SJW=0x01;
;TSEG1=0x08;
;TSEG2=0x07;

; lowspeed:
Interface=2;
Presc=0x0A;
SJW=0x02;
TSEG1=0x05;
TSEG2=0x02;
Reason 2: A SGBD is loaded in the Tool Set when the diagnosis protocol UDS is being
used. You use the interface OMITEC but the connector isn’t stressed by the
voltage (no blue blinking).
Solution 2: Connect the OMITEC wit the vehicle. The OMITEC connector has to be stressed
by the voltage (blue blinking). If the connector can’t be stressed by the voltage
and You want to load the SGBD yet, You will use the simulation mode. You can
activate the simulation mode e.g. with the menue „configuration -> EDIABAS“.
Notice, if you want to use the simulation mode, a simulation file for the interface
will have to exist in the simulation path

12 INPA BMW EDIABAS Error 134: API-0014: Result not found

The error occurs if a SGBD is loaded in the Tool Set when the diagnosis protocol UDS is
being used and the Job FS_LESEN is being executed.
Reason: You use the setting “read error like INPA”, but the Toolset can’t support the
function yet for UDS-SGBDs.
Solution: Please remove the setting “read error like INPA” in the menue “configuration ->
Toolset”.

13 INPA BMW takes too long to load an SGBD in the Tool S

Loading motor or transmission SGBDs takes an above average amount of time.
Reason: Large SGBDs often contain many and extensive tables and their information has
to be loaded.
Solution: Under the Configuration menu item in the Tool Set and then Tool Set, the
checkmark by the selection of table information must be removed

14.INPA BMW Black Windows in the Tool Set

After loading a SGBD one or more windows of the Tool Set are black windows.
Reason: The registration of the richtextbox is invalid.
Solution: You have to register the richtextbox. Execute the batch file REGSVR32.BAT in
the directory C:Ediabasbin

Finally ,for more detail information about INPA BMW ,pls click:
